| Item | Product Name | Focus Distance(mm) |
Diameter (mm) |
Spring Stiffness (N/mm) | Damper Power | |
| 1 | FT125 | Front | 718±3 | Φ12.1 | K1=4.8N/mm K2=7.6N/mm | Pf=127±39N/0.5m/s |
| 2 | Rear | 320±2 | Φ10.1 Φ12.1 | K1=17N/mm K2=30.5N/mm | Pf=637±98N/0.5m/s Py=245±59N/1m/s | |
| 3 | JH125 | Front | 717.4±3 | Φ12.1 | K1=4.4N/mm K2=6.9N/mm | Pf=127±39N/0.5m/s |
| 4 | Rear | 305.9±2 | Φ10.1 Φ12.1 | K1=17N/mm K2=30.5N/mm | Pf=637±98N/0.5m/s Py=245±59N/1m/s | |
| 5 | CB125T | Front | 735.4±3 | Φ15.1 | K1=4.1N/mm K2=7.5N/mm | Pf=150±40N/0.5m/s Py=40N/0.5m/s |
| 6 | Rear | 244±2 | Φ8.1 Φ8.1 | K1=177N/mm K2=290N/mm | Pf=1960±490N/0.1m/s Py=550±165N/0.1m/s | |
| 7 | CG125 | Front | 660±3 | Φ12.1 | K1=4N/mm K2=6.2N/mm | Pf=100±30N/0.5m/s |
| 8 | Rear | 308.5±2 | Φ12.1 Φ12.1 | K1=18.5N/mm K2=2.57N/mm | Pf=441±110N/0.5m/s | |
| 9 | JH90-A | Front | 640±3 | Φ10.1 | K1=4.4N/mm K2=6.6N/mm | Pf=100±30N/0.5m/s |
| 10 | Rear | 340.7±2 | Φ10.1 Φ12.1 | K1=16.5N/mm K2=35.1N/mm | Pf=637±98N/0.5m/s Py=245±59N/1m/s | |
| 11 | GN125 | Front | 765±3 | Φ12.1 | K1=3.5N/mm K2=8.7N/mm | Pf=70±20N/0.3m/s |
| 12 | Rear | 276±2 | Φ12.1 Φ12.1 | K1=14.7N/mm K2=26N/mm | Pf=412±82N/0.3m/s Py=245±59N/1m/s | |
| 13 | JD90 | Front | 420±2 | Φ10.1 | K1=4.5N/mm K2=5.3N/mm | Pf=80±24N/0.5m/s |
| 14 | Rear | 331±2 | Φ10.1 Φ12.1 | K1=16.4N/mm K2=21.2N/mm | Pf=524±131N/0.5m/s | |
| 15 | QM125-6 | Front | 814±3 | Φ12.1 | K1=2.7N/mm K2=7.4N/mm | Pf=98±30N/0.3m/s |
| 16 | Rear | 307.4±2 | Φ12.1 Φ12.1 | K1=14.1N/mm K2=23.5N/mm | Pf=300±60N/0.3m/s Py=300±60N/1m/s | |
| 17 | QM100-3 | Front | 735.4±3 | Φ15.1 | K1=4.1N/mm K2=7.5N/mm | Pf=150±40N/0.5m/s |
| 18 | Rear | 280±2 | Φ12.1 Φ12.1 | K1=16.6N/mm K2=30.1N/mm | Pf=412±82N/0.3m/s Py=245±59N/1m/s | |
| 19 | XDZ250 | Front | 763±3 | Φ15.1 | K1=3.2N/mm K2=5.6N/mm | Pf=190±50N/0.5m/s Py=50±15N/0.5m/s |
| 20 | Rear | 263±1.5 | Φ10.1 Φ14 | K1=28N/mm K2=44N/mm | Pf=650±163N/0.3m/s Py=90±27N/0.5m/s | |
| 21 | JY110 | Front | 410.2±2.5 | Φ10.1 | K1=3.9N/mm K2=8.4N/mm | Pf=118±35N/0.3m/s |
| 22 | Rear | 252.8±2 | Φ10.1 Φ12.1 | K1=17.4N/mm K2=42.6N/mm | Pf=294±59N/0.3m/s | |
| 23 | JL100T | Front | 368±2 | Φ10.1 | K1=5.7N/mm K2=11.6N/mm | Pf=98±30N/0.3m/s |
| 24 | Rear | 226±2 | Φ8.5 Φ10.1 | K1=42N/mm K2=50N/mm | Pf=600±150N/0.5m/s | |
| 25 | LF250 | Front | 765±3 | Φ15.1 | K1=4N/mm K2=6N/mm | Pf=270±68N/0.5m/s |
| 26 | Rear | 298.5±2 | Φ13.5 Φ13.5 | K1=20N/mm K2=45N/mm | Pf=600±150N/0.5m/s Py=245±59N/1m/s | |
| 27 | DY100 | Front | 417.5±1.5 | Φ12.1 | K=3.9N/mm | Pf=118±39N/0.5m/s |
| 28 | Rear | 331±2 | Φ10.1 Φ12.1 | K1=15N/mm K2=25N/mm | Pf=540±90N/0.5m/s | |
| 29 | JH125L2 | Front | 791.5±3 | Φ12.1 | K1=5.6N/mm K2=10.2N/mm | Pf=225±45N/0.5m/s Py=200±50N/1m/s |
| 30 | Rear | 389.5±2 | Φ10.1 Φ12.1 | K1=13.7N/mm K2=14.2N/mm | Pf=588±118N/0.5m/s Py=343±78N/1m/s | |
| 31 | JS125-5B | Front | 718±3 | Φ12.1 | K1=4.4N/mm K2=6.9N/mm | Pf=127±39N/0.3m/s |
| 32 | Rear | 305±2 | Φ10.1 Φ12.1 | K1=16.3N/mm K2=28N/mm | Pf=640±160N/0.5m/s Py=245±59N/1m/s | |
| 33 | TBT125 | Front | 422.2±2 | Φ12.1 | K=4.1N/mm | Pf=80±24N/0.5m/s |
| 34 | Rear | 328±2 | Φ10.1 Φ12.1 | K1=13.5N/mm K2=27.2N/mm | Pf=465±93N/0.5m/s | |
| 35 | 171 | Front | 420±2 | Φ12.1 | K1=4.5N/mm K2=5.3N/mm | Pf=80±24N/0.5m/s |
| 36 | Rear | 346±2 | Φ10.1 Φ12.1 | K1=13.4N/mm K2=26.9N/mm | Pf=465±93N/0.5m/s | |
| 37 | ZS250 | Front | 765±2 | Φ15.1 | K1=4N/mm K2=6N/mm | Pf=270±68N/0.5m/s |
| 38 | Rear | 298.5±2 | Φ13.5 Φ13.5 | K1=17N/mm K2=25N/mm | Pf=600±150N/0.3m/s Py=245±74N/1m/s | |
| 39 | JS150 | Front | 768±2 | Φ15.1 | K1=3.2N/mm K2=5N/mm | Pf=108±21N/0.5m/s |
| 40 | Rear | 320±2.5 | Φ14 Φ14 | K1=13.9N/mm K2=23.9N/mm | Pf=637±98N/0.5m/s Py=245±59N/1m/s | |
| 41 | 197 | Front | 735.4±3 | Φ15.1 | K1=4.1N/mm K2=7.5N/mm | Pf=150±40N/0.5m/s |
| 42 | Rear | 251±2 | Φ8.1 Φ8.1 | K=177N/mm | Pf=2260±560N/0.1m/s Py=700±200N/0.1m/s | |
| 43 | 196 | Front | 780±3 | Φ15.1 | K1=3.6N/mm K2=5.4N/mm | Pf=110±27N/0.3m/s |
| 44 | Rear | 310±2 | Φ12.1 Φ12.1 | K1=20.5N/mm K2=48N/mm | Pf=620±98N/0.5m/s | |
| 45 | JS125-27 | Front | 706±3 | Φ12.1 | K1=4N/mm K2=6.5N/mm | Pf=98±25N/0.3m/s |
| 46 | Rear | 309.4±2 | Φ12.1 Φ12.1 | K1=16.5N/mm K2=30N/mm | Pf=412±103N/0.3m/s Py=294±88N/1m/s | |
| 47 | CD70 | Front | 616±2 | Φ10.1 | K1=4.3N/mm K2=7.2N/mm | Pf=100±30N/0.5m/s |
| 48 | Rear | 340.7±2 | Φ10.1 Φ12.1 | K1=18N/mm K2=32N/mm | Pf=441±110N/0.5m/s | |
| 49 | LJ110-2 | Front | 420±2 | Φ12.1 | K1=4.2N/mm K2=9.1N/mm | Pf=118±39N/0.5m/s |
| 50 | Rear | 339±2 | Φ10.1 Φ12.1 | K1=16.4N/mm K2=21.2N/mm | Pf=524±131N/0.5m/s | |
| 51 | LJ110-8 | Front | 420±2 | Φ12.1 | K1=4.2N/mm K2=9.1N/mm | Pf=80±24N/0.5m/s |
| 52 | Rear | 345±2 | Φ10.1 Φ12.1 | K1=20.1N/mm K2=41.3N/mm | Pf=524±131N/0.5m/s | |
| 53 | LJ110-9 | Front | 420±2 | Φ12.1 | K1=4.2N/mm K2=9.1N/mm | Pf=110±33N/0.5m/s |
| 54 | Rear | 352±2 | Φ10.1 Φ12.1 | K1=19N/mm K2=39N/mm | Pf=524±131N/0.5m/s | |
| 55 | JS125-5A | Front | 718±3 | Φ12.1 | K1=2.9N/mm K2=7.8N/mm | Pf=127.4±25N/0.5m/s |
| 56 | Rear | 310±2 | Φ10.1 Φ12.1 | K1=17.4N/mm K2=22.5N/mm K3=60N/mm | Pf=725±125N/0.5m/s Py=200±50N/1m/s | |
| 57 | GS125 | Front | 720±3 | Φ12.1 | K1=4N/mm K2=6.5N/mm | Pf=98±25N/0.3m/s |
| 58 | Rear | 310±2 | Φ12.1 Φ12.1 | K1=23N/mm K2=30N/mm | Pf=412±103N/0.3m/s Py=294±88N/1m/s | |
| 59 | JS150-AF2 | Front | 768±3 | Φ15.1 | K=4N/mm | Pf=200±40N/0.5m/s |
| 60 | Rear | 335±2.5 | Φ14 Φ14 | K1=13.9N/mm K2=23.9N/mm | Pf=637±98N/0.5m/s Py=245±59N/1m/s | |
| 61 | 415 | Front | 717.4±3 | Φ12.1 | K1=2.8N/mm K2=7.5N/mm | Pf=110±22N/0.5m/s |
| 62 | Rear | 308±2 | Φ10.1 Φ12.1 | K1=19N/mm K2=31.5N/mm | Pf=602±110N/0.3m/s Py=245±59N/1m/s | |
| 63 | JS125-6B | Front | 708.7±3 | Φ12.1 | K1=3.3N/mm K2=7N/mm | Pf=98±25N/0.3m/s Py=170±42N/0.5m/s |
| 64 | Rear | 343±2 | Φ14 Φ14 | K1=13.3N/mm K2=16.2N/mm K3=24.3N/mm | Pf=280±60N/0.3m/s Py=350±70N/1m/s | |
| 65 | 197F | Front | 735.4±3 | Φ15.1 | K1=2.9N/mm K2=6.9N/mm | Pf=190±30N/0.5m/s |
| 66 | Rear | 251±2 | Φ8.1 Φ8.1 | K=177N/mm | Pf=2260±560N/0.1m/s Py=700±200N/0.1m/s | |
| 67 | LJ125-11 | Front | 708.5±3 | Φ12.1 | K1=3.7N/mm K2=10.4N/mm | Pf=98±25N/0.3m/s |
| 68 | Rear | 309.4±2 | Φ12.1 Φ12.1 | K1=22N/mm K2=40N/mm | Pf=412±103N/0.3m/s Py=294±88N/1m/s | |
| 69 | JY-5 | Front | 393±2 | Φ10.1 | K1=2.8N/mm K2=7N/mm | Pf=118±39N/0.5m/s |
| 70 | Rear | 310±2 | Φ10.1 Φ10.1 | K1=18N/mm K2=24.5N/mm | Pf=441±110N/0.5m/s | |
| 71 | JY-6 | Front | 363±2 | Φ10.1 | K1=2.8N/mm K2=5N/mm | Pf=118±39N/0.5m/s |
| 72 | Rear | 145±2 | Φ10.1 Φ10.1 | K1=36N/mm K2=45N/mm | ||
| 73 | 426 | Front | 722±3 | Φ12.1 | K1=3.7N/mm K2=11.9N/mm | Pf=98±25N/0.5m/s |
| 74 | Rear | 310±2 | Φ12.1 Φ12.1 | K1=16.7N/mm K2=26.8N/mm | Pf=425±82N/0.3m/s Py=294±59N/1m/s | |
| 75 | 351 | Front | 409±2 | Φ12.1 | K1=4.7N/mm K2=7.5N/mm | Pf=120±24N/0.3m/s Py=60±20N/0.3m/s |
| 76 | Rear | 346±2 | Φ10.1 Φ10.1 | K1=15N/mm K2=29.5N/mm | Pf=550±108N/0.3m/s Py=60N±20/0.3m/s | |
| 77 | JS110-B | Front | 420±2.5 | Φ10.1 | K1=4.1N/mm K2=6.3N/mm | Pf=80±30N/0.5m/s |
| 78 | Rear | 257.8±2 | Φ10.1 Φ12.1 | K1=17.9N/mm K2=42.9N/mm | Pf=294±59N/0.3m/s | |
| 79 | JS110-BG | Front | 420±2.5 | Φ10.1 | K1=4.1N/mm K2=8.5N/mm | Pf=130±33N/0.3m/s |
| 80 | Rear | 257.8±2 | Φ10.1 Φ12.1 | K1=18N/mm K2=43N/mm | Pf=370±70N/0.3m/s | |
| 81 | 318C | Front | 766.5±3 | Φ15.1 | K1=2.9N/mm K2=6.9N/mm | Pf=170±40N/0.5m/s |
| 82 | Rear | 252±2 | Φ8.1 Φ8.1 | K=177N/mm | Pf=3000±600N/0.1m/s Py=700±200N/0.1m/s | |
| 83 | JY-1 | Rear | 278±2 | Φ10.1 Φ10.1 | K1=18N/mm K2=24.5N/mm | Pf=441±110N/0.5m/s |
| 84 | JY-2 | Rear | 290±2 | Φ10.1 Φ10.1 | K1=18N/mm K2=32N/mm | Pf=441±110N/0.5m/s |
| 85 | JY-3 | Rear | 278±2 | Φ10.1 Φ10.1 | K1=18.4N/mm K2=24.4N/mm | Pf=441±110N/0.5m/s |
| 86 | JY-4 | Rear | 270±2 | Φ10.1 Φ10.1 | K1=18N/mm K2=32N/mm | Pf=441±110N/0.5m/s |
| 87 | JD70 | Rear | 212±1.5 | Φ8.3 Φ12.1 | K1=20.6N/mm K2=39.8N/mm | Pf=524±131N/0.5m/s |
| 88 | JS90 | Rear | 305.9±2 | Φ10.1 Φ12.1 | K1=17N/mm K2=30.5N/mm | Pf=637±98N/0.5m/s Py=245±59N/1m/s |
| 89 | JL70-2 | Rear | 326.5±2 | Φ10.1 Φ12.1 | K1=13.3N/mm K2=35.6N/mm | Pf=440±75N/0.5m/s |
| 90 | XF125 | Rear | 317±2 | Φ12.1 Φ12.1 | K1=25N/mm K2=43N/mm | |
